Max. Speed (km/h)   99
Dimension (L*W*H)(mm) Overall 12000*2500*3340
Curb weight (kg) 24300
Wheel base (mm)   1800+4500+1350
Appro. / depar. (°)  18 / 12
Engine WP10.340E32 (WEICHAI, Euro 2)
Horsepower 340hp
Gearbox 9JS135
Cab F3000 cab with A/C, with one sleeper
Axle Front 5.5 Ton MAN tech.
Rear 2 * 11.5 Ton MAN single reduction axle
Tire 12R22.5 (12+1)
Fuel tank 380L metal tank
Specification for the wrecker
Supporting system Max Supporting Capacity(kg) 12000
  Max Supporting Capacity when Fully Stretched out(kg) 8000
  Supporting Capacity in Situ(kg) 18000
  Effective Supporting Length(mm) 1460~3099
  Arm Extension Length(mm) 1639
Hoisting System Max Hoisting Capacity(kg) 20000
  Max Hoisting Capacity when Fully Stretched out(Min Elevation Angle) 8000
  Max Length of Arm(mm) 8470
  Oil Cylinder Extension Length(mm) 3300
  Max Hoisting Height (mm) 6500
Winch Quantity 2
  Rated Traction Force(kN) 100×2
  Wirerope Diameter(mm) φ18
  Wirerope Length(m) 45×2
Payment terms T/T,30% deposit, balance before delivery
Production time 50 working-day
Unit price USD 81,000 CIF Kingston,Jamaica port
(SAY EIGHTY ONE THOUSAND USD ONLY)
