Max. Speed (km/h) 99
Dimension (L*W*H)(mm) Overall 12000*2500*3340
Curb weight (kg) 24300
Wheel base (mm) 1800+4500+1350
Appro. / depar. (°) 18 / 12
Engine WP10.380E32 (WEICHAI, Euro 2)
Horsepower 380hp
Gearbox 9JS135
Cab F3000 cab with A/C, with one sleeper
Axle Front 5.5 Ton MAN tech.
Rear 2 * 11.5 Ton MAN single reduction axle
Tire 12R22.5 (12+1)
Fuel tank 380L metal tank
Specification for the wrecker
Supporting system Max Supporting Capacity(kg) 13600
Max Supporting Capacity when Fully Stretched out(kg) 7500
Supporting Capacity in Situ(kg) 30000
Effective Supporting Length(mm) 3870
Arm Extension Length(mm) 2090
Hoisting System Max Hoisting Capacity(kg) 30000
Rotator Angle 360 degree
Max Hoisting Height (mm) 11100
Winch Quantity 2
Rated Traction Force(kN) 150×2
