Main Beam Height:500mm, upper plate is 16mm,middle is 8mm(double+three plate),
down plate is 18mm,material is Q345B steel
Axle 3 axles, 13T/16T/20T, FUWA/BPW Brand
Landing Gear JOST Brand
King Pin JOST 2.00 OR 3.5 inch
Suspension Mechanical suspension (Germany Type Or America Type) or Air suspension
Spring Leaf 90(W)mm*13(Thickness)mm*10 Layer(especial for exporting market)
Break Systerm WABCO RE 6 relay valve ; T30/30+T30 Spring brake chamber(TKL brand);

Two pieces of 45L air tanks or China brand

Rim 9.00-22.5/8.00-20/8.5-20
Tire 12.00R22.5/315 80R22.5 / 11.00R20 / 12.00R20 Brand can be optional
ABS Optional
Valve Wabco valve
Light LED light (especial for exporting market)
Voltage 24V
Receptacle 7ways (7 wire harness)
Painting Complete Chassis sand blasting to clean rust, 1 coat of anticorrosive prime,

2 coats of final paint

Tool Box One piece ,1m*0.5m*0.5m(Size can be choose freely)(Equipped with 1 unit Tire

spanner, 1 unit gudgeon sleeve and i unit cranking bar)

Shipping Terms By bulk cargo carrier or RORO, the trailer size can be design according to your
special requirement, the tractor truck can be 6*4 model.
