Technical Parameters
Tanker Body
Dimension(mm) 12000mm×2500mm×4000mm
Tare weight About 11500kg
Total Volume (m³) 55 m³
Tanker Body Material 5mm Q235 carbon steel
End Plate 6mm Q235 carbon steel
Manhole Cover Carbon steel API manhole cover, 500mm(diameter)
Bottom Valve Carbon steel API Pneumatic Bottom Valve
Discharging Valve Diameter is 4 inch
Number Of Compartments 1
Discharging Pipe 4”rubber hose, 2 pcs , 6m/each
Engine Diesel engine;Weichai brand model: 4102
Air compressor Bohai brand 12m³
Chassis
Main Beams Welded design or Special design I beam, connected by bolts and nutsQ345 carbon steel material
Axle 3 axles,FUWA brand
Landing Gear CHINA BRAND 28T
King Pin 3.5 inch bolt-in king pin
Suspension Mechanical suspension
Leaf Spring 90(W)mm×13(Thickness)mm×10 layers
Pneumatic Braking System WABCO RE 6 relay valve; Spring brake chamber (TKL brand ); one piece of 45L air tank
Rim 9-22.5
Tire 12.00R22.5
Painting Sandblasted, anti-rust chassis surface is available with 1 layer of anticorrosive primer and 2 layers of top coats.
Accessories One standard tool box
