| Parameter | Tank Volume |
15000 Liters |
| Overall Dimension |
9800x2500x3350mm | |
| G.V.W |
25000kg | |
| Payload |
12500kg | |
| Kerb Weight |
12250kg | |
| Approach/Departure Angle(°) | 20/15 | |
| Fuel Type |
diesel | |
| Chassis | Drive type |
6×4 |
| Wheelbase |
4350+1350mm | |
| Tread(front/rear) |
1940/1860mm | |
| Steering gear | Duel-armed steering wheel, power steering |
|
| Transmission | 8 gear mechnical drive forward, 1 reverse gear |
|
| Clutch | Diaphragm clutch, hydraulic remote control, pneumatic servo |
|
| Braking system | Split air braking system, spring braking, exhaust braking |
|
| Cabin |
whole metal enclosed,three seats | |
| No of spring axles(front/rear) | 8/10+8 | |
| Tire |
11.00-20 | |
| Air-conditional |
chose to fix | |
| Engine | Engine model |
WP10.29 |
| Displacement/Power |
9726cc/221kw | |
| Type | six cylinder inner cooling supercharged diesel engine | |
| Suction spec | vertical suction range | <8m |
| Absolute pressure |
8500pa | |
| Rotation speed |
500rpm | |
| Theory pumping speed | 98L/s |
|
| Axis power |
5.5kw | |
| Vent diameter |
50mm | |
| Suction time |
<5 min | |
| Drain time |
<4 min |
